I wrote previously about setting up a Jupyter notebook in a Docker container. This worked well for a single user, but we intend to hold a workshop and so need a multi-user setup.

We would prefer that as much of the per-user setup as possible be completed automatically so participants don’t need to waste time setting up the environment.

There is a great resource at jupyterhub/jupyterhub-the-hard-way walking you through the manual setup.

However, there are many Docker containers that we can use as the base, including python:3.11, but I have decided to use jupyter/data science:latest. The containers are expected to be customised with a Dockerfile.

In my Dockerfile, I first installed JupyterLab and the other dependencies to avoid users needing to install these manually later.

RUN pip install --no-cache-dir \
    jupyterhub \
    jupyterlab \
    notebook \
    numpy \
    matplotlib \
    scikit-learn \
    ipyleaflet \
    ipywidgets \
    ipykernel

Then the system dependencies. A selection of editors and git which is needed for pip install git+https.

USER root
RUN apt-get update && apt-get install -y \
    curl git vim nano \
    && rm -rf /var/lib/apt/lists/*

Then our custom package from GitHub.

RUN pip install git+https://github.com/ucam-eo/geotessera.git

The default user database is PAM, so create UNIX users for the workshop participants without a disabled password.

RUN for user in user1 user2 user3; do \
        adduser --disabled-password --gecos '' $user; \
    done

Finally, set the entrypoint for the container:

CMD ["jupyterhub", "-f", "/srv/jupyterhub/jupyterhub_config.py"]

Next, I created the jupyterhub_config.py. I think most of these lines are self-explanatory. The password is the same for everyone to sign in. Global environment variables can be set using c.Spawner.environment.

from jupyterhub.auth import DummyAuthenticator

c.JupyterHub.authenticator_class = DummyAuthenticator
c.DummyAuthenticator.password = "Workshop"

# Allow all users
c.Authenticator.allow_all = True

# Use JupyterLab by default
c.Spawner.default_url = '/lab'

# Set timeouts
c.Spawner.start_timeout = 300
c.Spawner.http_timeout = 120
c.Spawner.environment = {
    'TESSERA_DATA_DIR': '/tessera'
}

# Basic configuration
c.JupyterHub.ip = '0.0.0.0'
c.JupyterHub.port = 8000

I’m going to use Caddy as a reverse proxy for this setup, for this I need a Caddyfile containing the public FQDN and the Docker container name and port:

workshop.cam.ac.uk {
	reverse_proxy jupyterhub:8000
}

The services are defined in docker-compose.yml; Caddy and the associated volumes to preserve SSL certificates between restarts, jupyterhub with volumes for home directories so they are preserved and a mapping for our shared dataset.

services:
  caddy:
    image: caddy:latest
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./Caddyfile:/etc/caddy/Caddyfile
      - caddy_data:/data
      - caddy_config:/config

  jupyterhub:
    build: .
    volumes:
      - ./jupyterhub_config.py:/srv/jupyterhub/jupyterhub_config.py
      - jupyter_home:/home
      - tessera_data:/tessera

volumes:
  caddy_data:
  caddy_config:
  jupyter_home:
  tessera_data:

Reset UFW to defaults

ufw --force reset

Set default policies

ufw default deny incoming
ufw default allow outgoing

Allow SSH and HTTP(S) services

ufw allow ssh
ufw allow http
ufw allow https

Enable UFW

ufw enable

Check status

ufw status verbose
