If you were following along with my previous post on containerd on Windows, you may recall that I lamented the lack of an installer. Since then, I have found a PowerShell script on Microsoft’s GitHub, which does a lot of the grunt work for us.
Trying anything beyond my echo Hello test showed an immediate problem: there is no network. ipconfig didn’t display any network interfaces.
C:\>ctr run --rm mcr.microsoft.com/windows/nanoserver:ltsc2022 my-container ipconfig
Windows IP Configuration
Checking the command line options, there is one called --net-host, which sounded promising, only for that to be immediately dashed:
C:\>ctr run --rm --net-host mcr.microsoft.com/windows/nanoserver:ltsc2022 my-container ipconfig
ctr: Cannot use host mode networking with Windows containers
The solution is --cni, but more work is required to get that working. We need to download the plugins and populate them in the cni/bin subdirectory. Fortunately, the installation script does all of this for us but leaves it unconfigured.
C:\Windows\System32>ctr run --rm --cni mcr.microsoft.com/windows/nanoserver:ltsc2022 my-container ipconfig
ctr: no network config found in C:\Program Files\containerd\cni\conf: cni plugin not initialized
From the top, this is how you get from a fresh install of Windows 11, to a container with networking. Firstly, use installation script to install containerd.
curl.exe https://raw.githubusercontent.com/microsoft/Windows-Containers/refs/heads/Main/helpful_tools/Install-ContainerdRuntime/install-containerd-runtime.ps1 -o install-containerd-runtime.ps1
Set-ExecutionPolicy Bypass
.\install-containerd-runtime.ps1 -ContainerDVersion 2.1.1 -WinCNIVersion 0.3.1 -ExternalNetAdapter Ethernet
Now create C:\Program Files\containerd\cni\conf\0-containerd-nat.conf containing the following:
{
"cniVersion": "0.3.0",
"name": "nat",
"type": "nat",
"master": "Ethernet",
"ipam": {
"subnet": "172.20.0.0/16",
"routes": [
{
"gateway": "172.20.0.1"
}
]
},
"capabilities": {
"portMappings": true,
"dns": true
}
}
Easy when you know how…
C:\>ctr run --rm --cni mcr.microsoft.com/windows/nanoserver:ltsc2022 my-container ping 1.1.1.1
Pinging 1.1.1.1 with 32 bytes of data:
Reply from 1.1.1.1: bytes=32 time=5ms TTL=58
Reply from 1.1.1.1: bytes=32 time=7ms TTL=58
Reply from 1.1.1.1: bytes=32 time=7ms TTL=58
Reply from 1.1.1.1: bytes=32 time=6ms TTL=58
Ping statistics for 1.1.1.1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 5ms, Maximum = 7ms, Average = 6ms
The next challenge is, what do you put in your own config.json to reproduce this behaviour?
Firstly, we need our layerFolders:
C:\>ctr snapshot ls
KEY PARENT KIND
sha256:44b913d145adda5364b5465664644b11282ed3c4b9bd9739aa17832ee4b2b355 Committed
C:\>ctr snapshot prepare --mounts my-snapshot sha256:44b913d145adda5364b5465664644b11282ed3c4b9bd9739aa17832ee4b2b355
[
{
"Type": "windows-layer",
"Source": "C:\\ProgramData\\containerd\\root\\io.containerd.snapshotter.v1.windows\\snapshots\\14",
"Target": "",
"Options": [
"rw",
"parentLayerPaths=[\"C:\\\\ProgramData\\\\containerd\\\\root\\\\io.containerd.snapshotter.v1.windows\\\\snapshots\\\\1\"]"
]
}
]
Let’s create a config.json without a network stanza just to check we can create a container:
{
"ociVersion": "1.1.0",
"process": {
"terminal": false,
"user": { "uid": 0, "gid": 0 },
"args": [
"cmd", "/c",
"ipconfig && ping 1.1.1.1"
],
"cwd": "c:\\"
},
"root": { "path": "", "readonly": false },
"hostname": "builder",
"windows": {
"layerFolders": [
"C:\\ProgramData\\containerd\\root\\io.containerd.snapshotter.v1.windows\\snapshots\\1",
"C:\\ProgramData\\containerd\\root\\io.containerd.snapshotter.v1.windows\\snapshots\\14"
],
"ignoreFlushesDuringBoot": true
}
}
The container runs, but there is no network as we’d expect.
C:\>ctr run --rm --config config.json my-container
Windows IP Configuration
Pinging 1.1.1.1 with 32 bytes of data:
PING: transmit failed. General failure.
PING: transmit failed. General failure.
PING: transmit failed. General failure.
PING: transmit failed. General failure.
If we turn on CNI, it crypically tells us what we need to do:
C:\>ctr run --rm --cni --config config.json my-container
ctr: plugin type="nat" name="nat" failed (add): required env variables [CNI_NETNS] missing
So we need to populate the network.networkNamespace with the name (ID) of the network we want to use. This should be a GUID, and I don’t know how to get the right value. I would have assumed that it was one of the many GUID’s returned by Get-HnsNetwork but it isn’t.
PS C:\> Get-HnsNetwork
ActivityId : 92018CF0-6DCB-4AAF-A14E-DC61120FC958
AdditionalParams :
CurrentEndpointCount : 0
Extensions : {@{Id=E7C3B2F0-F3C5-48DF-AF2B-10FED6D72E7A; IsEnabled=False; Name=Microsoft Windows Filtering Platform},
@{Id=F74F241B-440F-4433-BB28-00F89EAD20D8; IsEnabled=False; Name=Microsoft Azure VFP Switch Filter Extension},
@{Id=430BDADD-BAB0-41AB-A369-94B67FA5BE0A; IsEnabled=True; Name=Microsoft NDIS Capture}}
Flags : 8
Health : @{LastErrorCode=0; LastUpdateTime=133943927149605101}
ID : 3EB2B18B-A1DD-46A8-A425-256F6B3DF26D
IPv6 : False
LayeredOn : 20791F67-012C-4C9B-9C93-530FDA5DE4FA
MacPools : {@{EndMacAddress=00-15-5D-C3-DF-FF; StartMacAddress=00-15-5D-C3-D0-00}}
MaxConcurrentEndpoints : 1
Name : nat
NatName : NATAC317D6D-8A2E-4E4E-9BCF-33435FE4CD8F
Policies : {@{Type=VLAN; VLAN=1}}
State : 1
Subnets : {@{AdditionalParams=; AddressPrefix=172.20.0.0/16; Flags=0; GatewayAddress=172.20.0.1; Health=;
ID=5D56CE8D-1AD2-47FF-85A7-A0E6D530565D; IpSubnets=System.Object[]; ObjectType=5; Policies=System.Object[]; State=0}}
SwitchGuid : 3EB2B18B-A1DD-46A8-A425-256F6B3DF26D
TotalEndpoints : 2
Type : NAT
Version : 64424509440
Resources : @{AdditionalParams=; AllocationOrder=2; Allocators=System.Object[]; CompartmentOperationTime=0; Flags=0; Health=;
ID=92018CF0-6DCB-4AAF-A14E-DC61120FC958; PortOperationTime=0; State=1; SwitchOperationTime=0; VfpOperationTime=0;
parentId=71FB2758-F714-4838-8764-7079378D6CB6}
I ran ctr run --rm --cni mcr.microsoft.com/windows/nanoserver:ltsc2022 my-container cmd /c "ping 1.1.1.1 && pause" in one window and ran ctr c info my-container in another, which revealed a GUID was 5f7d467c-3011-48bc-9337-ce78cf399345.
Adding this to my config.json
{
"ociVersion": "1.1.0",
"process": {
"terminal": false,
"user": { "uid": 0, "gid": 0 },
"args": [
"cmd", "/c",
"ipconfig && ping 1.1.1.1"
],
"cwd": "c:\\"
},
"root": { "path": "", "readonly": false },
"hostname": "builder",
"windows": {
"layerFolders": [
"C:\\ProgramData\\containerd\\root\\io.containerd.snapshotter.v1.windows\\snapshots\\1",
"C:\\ProgramData\\containerd\\root\\io.containerd.snapshotter.v1.windows\\snapshots\\14"
],
"ignoreFlushesDuringBoot": true,
"network": {
"allowUnqualifiedDNSQuery": true,
"networkNamespace": "5f7d467c-3011-48bc-9337-ce78cf399345"
}
}
}
And now I have a network!
C:\>ctr run --rm --cni --config config.json my-container
Windows IP Configuration
Ethernet adapter vEthernet (default-my-container2_nat):
Connection-specific DNS Suffix . : Home
Link-local IPv6 Address . . . . . : fe80::921d:1ce7:a445:8dfa%49
IPv4 Address. . . . . . . . . . . : 172.20.95.58
Subnet Mask . . . . . . . . . . . : 255.255.0.0
Default Gateway . . . . . . . . . : 172.20.0.1
Pinging 1.1.1.1 with 32 bytes of data:
Reply from 1.1.1.1: bytes=32 time=5ms TTL=58
Reply from 1.1.1.1: bytes=32 time=6ms TTL=58
Reply from 1.1.1.1: bytes=32 time=6ms TTL=58
Reply from 1.1.1.1: bytes=32 time=6ms TTL=58
Ping statistics for 1.1.1.1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 5ms, Maximum = 6ms, Average = 5ms
